AF-ACID (Non-Metallic)
DURASILE AF ACID (Non-Metallic)
DURASILE AF-ACID is a compressed non-asbestos (CNAF) gasket material that has numerous applications in the process industries and in the water and chemical industries.
It is suitable for various highly aggressive media and very good chemical resistance to acid and alkaline media.
Composition :-
DURASILE AF-ACID gasket sheet is produced from a combination of mineral and aramid fibres which are bonded with synthetic elastomers (CSM). It is manufactured through the hot calendar process under rigorous quality control standards that are registered under ISO-9001 certification.
Compliance : ASTM F 104 Line call out: F 719911 E19 A9 B3 M6
| Technical Details | |
|---|---|
|
Maximum Peak Temperature °C |
400°C |
|
Maximum Operating Temperature °C |
275°C |
|
Maximum Peak Pressure (bar) |
150 bar |
|
Available Thickness (in mm) |
0.30 – 6.00 (other thickness available on request) |
|
Available Colors |
White (other colors available on request) |
|
Available Sheet Sizes (in mm) |
1500 X 1500, 1500 X 2000, 1500 X 2250, 1500 X 3000, 1500 X 4500, 2000 X 3000 |
- Diluted alkalis
- Aliphatic solvents
- General chemicals
- Water
- Industrial oils
- Refrigerants
- Petroleum and Derivatives
- Air
- Automotive and Engine Building Industries
- Gas Supply
- General Supply
- Shipbuilding
